Csővezetékek

The right pipeline control and instrumentation can make a huge difference in terms of performance and profitability. Yokogawa has dedicated technology that can optimize the performance of all elements of a pipeline solution, including compressors, pumps, valves, and intermediate storage and distribution facilities.

Kihívások

Customer Challenge

  • Need a single centralized control room to improve overall operation and management of the gas pipeline.
  • Need the backup and main master stations in separate locations for a disaster preparedness measure.
  • Collect manually the operation data for each of the regional pipelines.
Pipeline monitoring and control configuration

Our Solutions

  • For the central control room- provide the FAST/TOOLS package and a high availability computing solution that utilizes a history server, client server, and zonal server in a triple redundant configuration.
  • For each regional gas management center - implement a FAST/TOOLS-based solution that relies on dual redundant front-end processor servers, for uninterrupted monitoring and control.


Customer Benefits

  • With redundant configuration, the flow of operation and maintenance data from the field is ensured.
  • Operators, production engineers, and analysts have the real time visual access 24/7 through the year to the data.
  • System availability for the entire customer pipeline network has been increased to 99.5%.
Pipeline data view



Efficient Operation

Achievements

  • Ensured steady gas supply across the nation
  • Improved efficiency of operation and maintenance
  • Minimized Total Cost of Ownership



Enabling Technology

FAST/TOOLS

  • Originating as the Flexible Advanced System Techniques (FAST) project, FAST/TOOLS today is a comprehensive, fully-integrated SCADA application suite.
  • Powerful and flexible, FAST/TOOLS serves installations ranging from 50-point unit processes to multimillion-point offshore production and pipeline systems that extends over thousands of miles.
Flexible Advanced System Techniques (FAST)



Details

Overview

EPMS System

The Enterprise Pipeline Management Solution “EPMS” provides a collection of standard pipeline applications to facilitate the management and operations of gas/liquids pipeline systems. Applications can be seamlessly plugged into the FAST/TOOLS real-time system platform similar to SCADA monitoring and control environment. EPMS consist of two packages; Gas Enterprise Management Suite and Liquid Enterprise Management Suite.

Image Zoom





Benefit


The EPMS package brings the following benefits based on 20 years of experience in engineering medium to large complex pipeline automations.

EPMS Benefit

Pipeline Management System Implementation

  • Better and faster implementation
  • Knowledge centralization, retention and documentation
  • Enhanced lifecycle management
  • Reliable system using proved functions
  • Dedicated consultant and product support

Cost of Integration

  • Prevent application vendor and integration technology lock-in
  • Establish a standards-based and IT/Security compliant application platform

Reduced Cost of Ownership

  • Standard technology
  • Scalable, flexible, reusable
  • Lifecycle management

Industry Standards Support

  • Implement best practices from pipeline industry standards
  • Provide foundation for regulatory support and compliance

Future Proof

  • IT architecture hedges against disruptive technologies and trends
  • Increased process and data variety, volume, and velocity



Functional Specifications

Enterprise Pipeline Management Solutions (EPMS)

EPMS delivers the following interrelated and integrated functions;

  • Processing of meter inputs for accurate measurement and flow calculations
  • Management of gas data with the device scheduler and EFM log up-loader
  • Schedule and monitor gas nominations
  • Monitor the line-pack along the pipelines and segments
  • Maximum Allowable Operating Pressure, MAOP, monitoring
  • Pipeline balance, storage and inventory calculations
  • Schedule and track batches for efficient transportation of liquid products
  • Monitor liquid pipelines for leaks, inventory and hydraulic profiling
  • Drag reducing agent management and power management on compressors and pumps
  • Controlling a manifold with the flow path manager
  • Tracking and management of anomalies like pigs/scrapers, merge/hot spots and interfaces

      Image Zoom



Pipeline Application

Pipeline Application

Image Zoom



System Architecture

EPMS plugs into the FAST/TOOLS platform and inherits the FAST/TOOLS advantages in one common environment;

  • One system/user management and configuration environment
  • Same layout of pipeline displays can be used for process displays
  • Same user authorization can be used within the whole application
  • Standard features like reporting, history and configuration are available in the same environment

EPMS System Architecture
