Dual Spinning Disk Confocal Technology
As the pioneer in dual spinning disk confocal technology, Yokogawa has revolutionized live cell imaging in optical microscopy. The multi-beam scanning method offers not only high speed imaging but significantly reduced phototoxicity and photo bleaching, making our confocal scanner units the de facto standard tool for live cell imaging.
High-Speed, High Resolution Imaging
Yokogawa’s confocal scanners employ advanced imaging technologies to help researchers achieve high-speed and high-resolution live cell imaging.
- Fast time-lapse confocal images of living cells
- Minimal phototoxicity and less photobleaching
- Live-cell confocal fluorescence imaging capabilities
- Stability during long-term and high-speed imaging
- Facilitates quantitative analysis of huge amounts of data
Super Resolution via Optical Re-assignment.
Wide Field of View
The CSU-W1 is our answer to researchers’ requests for “Wider FOV” and “Clearer Images”.
The CSU-X1 is widely recognized as the leading tool for live cell imaging with 2,000 fps capability.
We post our information to the following SNSs.
Please follow us.
Yokogawa Life Science
|Yokogawa Life Science|
|Yokogawa Life Science|
|•YouTube||Life Science Yokogawa|
Yokogawa's Official Social Media Account List
Comparison of CSU series
|Disk unit||Selectable up to
Pinhole size :50µm, 25µm
Pinhole size :50µm
|External signal output possible||None*2|
|DM||Option (up to 3 filters)||Option
(up to 10 filters with
(up to 12 filters with
|At user site :DM block and filters (EX, EM.)
At Yokogawa factory :DM
Comparison between CSU and other confocal systems
multi beam scan
|Single beam scan||Line Scan||Disk scan (Multi beam or slit)||None|
|Light Source||Lasers||Hg or Xenon arc lamp|
|Detector||CCD, EMCCD||PMT||Line CCD||CCD, EMCCD|
|Microscope||Flexible||Specific||Flexible / Specific||Flexible|
|Scan speed of
|Confocality||High (X-Y-Z confocal)||Modest
(X-Y-Z confocal with pinhole,
|High Good S/N
with dim samples)
- Ted Salmon Lab., Dept. of Biology, University of North Carolina, Chapel Hill
- Waterman-Storer Lab., Laboratory of Cell and Tissue Morphodynamics (LCTM),NHLBI（Bethesda Campus)
- Tim Mitchison Lab., Dept. of Systems Biology, Harvard Medical School
- Scholey Lab., Dept. of Cell and Computational Biology, University of California, Davis
- The Vale Lab., Dept. of Cellular and Molecular Pharmacology, University of California, San Francisco
- The Wadsworth Lab., Biology Dept., University of Massachusetts, Amherst
- The Kiehart Lab., Dept. of Biology, Duke University
- HSC Core Facilities School of Medicine, University of Utah
- Indiana Center for Biological Microscopy, Indiana University Medical Center
- Ehlers Laboratory - Department of Neurobiology, Duke University
- Bob Goldstein Lab., University of North Carolina Chapel Hill
- Andrew Matus Lab., at Friedrich Miescher Institute for Biomedical Research
- Laboratory of Developmental Dynamics,Graduate School of Life Sciences, Tohoku University
- Zena Werb Lab., Anatomy, University of California San Francisco
- Satoshi Nishimura Lab., Dept. of Cardiovascular Medicine, the University of Tokyo
- Oshima Lab., Graduate School of Interdisciplinary Information Studies，The Univ. of Tokyo
- The Huser research group at UC Davis
- Nakano Lab., Graduate School of Science, University of Tokyo
1) Microscopy & Imaging Resources on the WWW
Complete list of all aspects of microscopy and imaging, by Douglas W. Cromey From Cellular Imaging Core of Southwest Environmental Health Sciences Center, University of Arizona College of Pharmacy, University of Arizona
2) The Centro de Biologia Molecular “Severo Ochoa” (CBMSO)
Contains links to general information, microscopy laboratories, publications, courses and meetings, societies, images. Especially useful for finding microscopy workshops.
3) The Cell Imaging Facility, a part of the University of Utah Health Science Center's Core Research Facilities Department
Good explanation of CSU-Disk scanning confocal system by Chris Rodesch
4) Molecular Expressions Website
Run by National High Magnetic Field Laboratory, Florida State University.
One of Web's largest collections of excellent optical microscopy images, and quite thorough information on all types of microscopy.
Interactive Java Tutorials sponsored by Nikon (Nikon MicroscopyU) and Olympus(Olympus Microscopy Resource Center) are extremely useful to learn not only confocal but all kinds of microscopies, and related technologies.
Life Science Textbooks
Microscopy Techniques, Advances in Biochemical Engineering/Biotechnology Vol.95
Confocal Microscopy for Biologists
Live Cell Imaging, A Laboratory Manual
Handbook of Biological Confocal Microscopy, 3rd Edition
VideoMicroscopy, The Fundamentals
Direct-View High-Speed Confocal Scanner: The CSU-10, Chapter 2: Cell Biological Applications of Confocal Microscopy (Methods in Cell Biology)
Articles: CSU Technology and its applications
|Quantification and clustering of actin cytoskeletal structures in plant cells: role of actin bundling in stomatal movement during diurnal cycles in Arabidopsis guard cells.
Higaki T, Kutsuna N, Sano T, Kondo N, Hasezawa S
|Current Application and Technology of Functional Multineuron Calcium Imaging.
Shigehiro Namiki and Yuji Ikegaya
Biological and Pharmaceutical Bulletin Vol.32(2009) , No.11
|Live imaging of yeast Golgi cisternal maturation.
Kumi Matsuura-Tokita, Masaki Takeuchi, Akira Ichihara, Kenta Mikuriya and Akihiko Nakano
Nature 441, 1007-1010 (22 June 2006)
|Performance comparison between the high-speed Yokogawa spinning disc confocal system and single-point scanning confocal systems.
E. Wang, C. M. Babbey & K. W. Dunn
Journal of Microscopy, Vol. 218, Pt 2 May 2005, pp. 148 ?159
|Optically sectioned fluorescence lifetime imaging using a Nipkow disk microscope and a tunable ultrafast continuum excitation source.
D.M.Grant, D.S. Elson, D.Schimpf, C.Dunsby, J.Requejo-Isidro, E.Auksorius, I.Munro, M.A. A. Neil, P. M. W. French ,E. Nye G. Stamp, P.Courtney
Optics Letters Vol. 30, No. 24 (2005 ) 3353
|Optimization of Spinning Disk Confocal Microscopy: Synchronization with the Ultra-Sensitive EMCCD.
F.K.Chong, C.G.Coates, D.J.Denvir, N.McHale, K.Thornbury & M.Hollywood
Proceedings of SPIE 2004
|Spinning disk confocal microscope system for rapid high-resolution, multimode, fluorescence speckle microscopy and green fluorescent protein imaging in living cells.
Maddox PS, Moree B, Canman JC, Salmon ED
Methods Enzymol. 360:597-617 (2003)
|A high-speed multispectral spinning-disk confocal microscope system for fluorescent speckle microscopy of living cells.
Adams, M.C., Salmon, W.C., Gupton, S.L., Cohan, C.S., Wittmann, T., Prigozhina, N. & Waterman-Storer, C.M
Methods, 29, 29?41 (2003)
|Spinning-disk confocal microscopy ? a cutting-edge tool for imaging of membrane traffic.
Cell Structure Function, 27, 349?355.(2002)
|High Speed 1-frame/ms scanning confocal microscope with a miclolens and Nipkow disks.
T.Tanaami, S.Otsuki,N.Tomosada, Y.Kosugi. M.Shimizu & H.Ishida
Applied Optics, Vol.41,No.22(2002)
|New imaging modes for lenslet-array tandem scanning microscopes.
T. F. Watson, R. Juskaitis & T. Wilson
Journal of Microscopy, Vol. 205, Pt 2 February (2002) 209?212
|High-speed confocal fluorescence microscopy using a Nipkow scanner with microlenses for 3-D imaging of single fluorescence molecule in real time.
A.Ichihara, T.Tanaami, K.Isozaki, Y.Sugiyama, Y.Kosugi, K.Mikuriya, M.Abe and I.Uemura
Bioimages 4, 57-62(1996)
Articles: Cell Biology
(Vesicular transport, actin dynamics, microtubule dynamics, cell division)
|Long-term, Six-dimensional Live-cell Imaging for the Mouse Preimplantation Embryo That Does Not Affect Full-term Development.
Yamagata, K., Suetsugu, R. and Wakayama, T., J. Reprod. Dev., 55: 328-331(2009) ”
|The Caenorhabditis elegans DDX-23, a homolog of yeast splicing factor PRP28, is required for the sperm-oocyte switch and differentiation of various cell types.
Konishi, T., Uodome, N., and Sugimoto, A.,Developmental Dynamics 237, 2367-2377(2008)
|Determining the position of the cell division plane.
J. C. Canman, L. A. Cameron, P.S. Maddox, A. Straight, J, S. Tirnauer, T. J. Mitchison, G. Fang., T. M. Kapoor & E. D. Salmon, Nature 424, 1074-1078 (28 August 2003) “Cover”
|Taxol-stabilized Microtubules Can Position the Cytokinetic Furrow in Mammalian Cells.
Katie B. Shannon, Julie C. Canman,C. Ben Moree,Jennifer S. Tirnauer, and E. D. Salmon, Mol Biol Cell. September; 16(9): 4423?4436 (2005)
|Two mitotic kinesins cooperate to drive sister chromatid separation during anaphase.
G. C. Rogers, S. L. Rogers, T. A. Schwimmer,S. C. Ems-McClung, .C E. Walczak, R. D. Vale, J. M. Scholey & D. J. Sharp, Nature 427(6972):, 364-370 (2004)
|Crm1 is a Mitotic Effector of Ran-GTP in Somatic Cells
Arnaoutov, A., Azuma, Y., Ribbeck, K., Joseph, J., Boyarchuk, Y. and Dasso, M, Nat Cell Biol. Jun;7(6):626-32 (2005).
|Nuclear congression is driven by cytoplasmic microtubule plus end interactions in S. cerevisiae.
J.N. Molk, E.D. Salmon, and K. Bloom, JCB, Vol. 172, Number 1, 27-39 (2006)
|Centrosome fragments and microtubules are transported asymmetrically away from division plane in anaphase
Nasser M. Rusan and Patricia Wadsworth ,JCB 168 (1) 21?28 (2005)
|The roles of microtubule-based motor proteins in mitosis: comprehensive RNAi analysis in the Drosophila S2 cell line.
G. Goshima and R.D. Vale,JCB 162(6) 1003?1016 (2003)
|Spindle orientation in Saccharomyces cerevisiae depends on the transport of microtubule ends along polarized actin cables.
Hwang, E., Kusch, J., Barral, Y. & Huffaker, T.C, J. Cell Biol. 161, 483?488 (2003)
|Cell migration without a lamellipodium : translation of actin dynamics into cell movement mediated by tropomyosin
S.L. Gupton, K.L. Anderson, T. P. Kole, R.S. Fischer, A. Ponti, S.E. Hitchcock-DeGregori, G. Danuser, V.M. Fowler, D.Wirtz, D. Hanein, and C.M. Waterman-Storer ,JCB 168(4) 619-631(2005)
|Actin dynamics in the contractile ring during cytokinesis in fission yeast.
Pelham, R.J. & Chang, F, Nature, 419, 82?86. (2002)
|CD8+ effector T cells contribute to macrophage recruitment and adipose tissue inflammation in obesity.
Nishimura S, Manabe I, Nagasaki M, Eto K, Yamashita H, Ohsugi M, Otsu M, Hara K, Sugiura S,Yoshimura K, Kadowaki T, Nagai R, Nature Medicine 8, 914- 920 (15 August 2009)
|T-cell engagement of dendritic cells rapidly rearranges MHC class II transport.
M. Boes, J. Cerny, R. Masso, M. Op den Brouw, T. Kirchhausen, J. Chenk & H. L. Ploegh, Nature 418, 983- 988 (29 August 2002) “Cover”
|Functional coordination of intraflagellar transport motors.
G. Ou, O.E. Blacque, J.J.Snow, M.R. Leroux & J.M. Scholey,Nature 436(7050):583-7. (2005).
|Three-dimensional analysis of post-Golgi carrier exocytosis in epithelial cells
Kreitzer, G., Schmoranzer, J., Low, S.H., Li, X., Gan, Y., Weimbs, T., Simon, S.M. & Rodriguez-Boulan, E, Nature Cell Biol. 5, 126?136. (2003)
|Dynamics of Membrane Clathrin-Coated Structures During Cytokinesis.
James H. & Wang, Yu-Li Warner, Anne K., Keen, Traffic 7 (2), 205-215. (2006 )
|Activity-induced targeting of profilin and stabilization of dendritic spine morphology.
Ackermann, M., and A. Matus, Nat Neurosci. Nov;6(11):1194-200 (2003)
|Dynamics and Regulation of Clathrin Coats at Specialized Endocytic Zones of Dendrites and Spines.
T.A. Blanpied, D.B. Scott, M.D. Ehlers, Neuron, Vol. 36, 435?449, October 24(2002)
|Neurabin/Protein Phosphatase-1 Complex Regulates Dendritic Spine Morphogenesis and Maturation.
R.T.Terry-Lorenzo, D.W. Roadcap, T. Otsuka , T.A. Blanpied, P.L. Zamorano, C.C. Garner, S. Shenolikar, and M.D. Ehlers, MBC Vol. 16, Issue 5, 2349-2362, May (2005)
|Phosphatidylinositol phosphate kinase type I regulates dynamics of large dense-core vesicle fusion.
L.W..Gong , G. D.Paolo, E. Diaz ., G.Cestra , M-E. Diaz, M. Lindau , P.De Camilli , and D. Toomre , PNAS, vol. 102 no. 14 5204-5209 (2005)
|Formation of planar and spiral Ca2+ waves in isolated cardiac myocytes.
Ishida, H., Genka, C., Hirota, Y., Nakazawa, H. & Barry, W.H, Biophys. J. 77, 2114?2122 (1999)
|Simultaneous imaging of phosphatidyl inositol metabolism and Ca2+ levels in PC12h cells.
Morita,M,Yoshiki, F,and ,Kudo,Y, BBRC 308, 673-678 (2003)
|Calcium oscillations in interstitial cells of the rabbit urethra.
Johnston, L., Sergeant, G. P., Hollywood, M. A., Thornbury, K. D. & McHale, N. G,The Journal of Physiology 565 (2), 449-461 (2005).
Microvascular Blood Flow
|Real-time observation of hemodynamic changes in glomerular aneurysms induced by anti-Thy-1 antibody.
Oyanagi-Tanaka, Y., Yao, J., Wada, Y., Morioka, T., Suzuki, Y., Gejyo, F., Arakawa, M. & Oite, T, Kidney Int. 59, 252?259. (2001)
|Real-time in vivo imaging of platelets, tissue factor and fibrin during arterial thrombus formation in the mouse.
Shahrokh Falati, Prter Gross, Glenn Merrill-Skoloff, Barbara C. Furie & Bruce Furie, Nat Med 8 (10) 1175-1180(2002)
|Evidence of ROS generation by mitochondria in cells with impaired electron transport chain and mitochondrial DNA damage
Hiroko P. Indo,Mercy Davidson,Hsiu-Chuan Yen,Shigeaki Suenaga,Kazuo Tomita,Takeshi Nishii,Masahiro Higuchi,Yasutoshi Koga,Toshihiko Ozawa,Hideyuki J. Majima,Mitochondrion No.7 106?118(2007)
Discovering the Basic Principles of Life through the Live Imaging of C. elegans
Wide and Clear
Confocal Scanner Unit
Long-term observation of mitosis by live-cell microscopy is required for uncovering the role of Cohesin on compartmentalized nuclear architecture which is linked to nuclear functions.
To perform long term observation of mitosis devices are needed that have low phototoxic effects on living cells and enable high speed imaging. By using the CSU W-1 confocal scanner unit for time lapse imaging entrance into mitosis, mitotic progression and exit can be examined.
Comparison between CSU and conventional LSM in 4D movies.
To investigate interactive dynamics of the intracellular structures and organelles in the stomatal movement through live imaging technique, a CSU system was used to capture 3-dimensional images (XYZN) and time-laps images (XYT) of guard cells.
List of Selected Publications : CSU-X1
List of Selected Publications : CSU-W1
Faster, Brighter, and More Versatile Confocal Scanner Unit
YOKOGAWA proprietary Spinning Disk technology enables fast real-time confocal imaging for applications such as high-speed 3D and long-term live cell imaging. These quantifiable imaging analysis are essential tools for modern precision drug discovery.
YOKOGAWA will contribute to technology evolution particularly in measurement and analytical tools to help build a world where researchers will increasingly focus on insightful interpretation of data, and advancing Life Science to benefit humanity.
