特种和精细化工

特种和精细化工的生产企业面临很多挑战。 研究驱动型创新、把切合客户需求的产品快速引入市场是实现盈利的关键。同时我们展望未来,提供能满足客户需求的产品和解决方案。

横河电机长期以来一直为特种和精细化工的客户提供服务。通过先进的批量解决方案、为客户提供良好的可靠性和灵活性,同时我们还拥有在复杂要求下设计批量解决方案的行业专家。您可以放心,在与横河电机合作期间我们将提供给您一个系统,使您能够在保证安全和遵从法规的前提下,生产满足客户需求的产品。

客户面临的挑战

化工公司不仅对产品质量有严格的要求,而且对产品工艺也有严格的规定。这也适用于化工行业规范分支的流程工厂的设计、安装和自动控制。

我们的解决方案

特种和精细化工产品通常用批量过程生产。为了适应范围更广的产品,这类工厂的生产系统必须非常灵活。凭借基于ISA-88的批处理功能,横河电机的综合控制解决方案CENTUM VP集散生产控制系统可以很好地满足要求。在过程分析和产品质量方面,批次性能数据必须以易于访问的格式存储。批量生产、设备和配方的现状和历史性能数据被基于ISA-88Exaquantum / Batch信息管理系统收集、保存、显示和报告。同时Exapilot在线导航工具可帮助操作员可靠执行诸如停车和启动等非常规程序。

使能技术

生产控制系统:CENTUM VP批量控制系统
化工产品批处理需要批量操作,其中一些具有功能性,可以制造多种不同产品,而实现这些需要使用缜密的批量控制系统。集散生产控制系统CENTUM VP,提供基于ISA-88 Batch标准的批处理功能。


过程信息管理系统:Exaquantum/Batch
批量生产和控制记录需要整体维护,可随时备查。这些信息还将用于决策支持、生产计划、过程分析、过程改进质量保证目的。Exaquantum / Batch是基于ISA-88的智能信息系统。它提供经过验证的分析和设备报告,用于批量生产、设备和配方操作中收集存储和显示当前和历史数据。


提高操作效率:Exapilot
Exapilot是一种在线导航工具,可指导操作员逐步完成工厂操作程序。
使用Exapilot按照规范格式创建标准操作程序(SOP)。通过减少或消除人为错误来提高效率并降低业主总成本。



客户面临的挑战

如电力、蒸汽、压缩空气能源的采购成本和可用性是不断变化的,特别是在大型工厂,它们是能源效率管理(EEM)的关键参数。

使能技术

明确的行动建议

工厂能效管理系统(PEEMS)是横河电机深入研究、全方位考虑后的EEM解决方案,可根据工厂的能耗提供合适的解决方案。

上述图表清楚地表明横河电机解决方案的基本原理和架构,通过这些操作可以帮助客户提高EEM

从现场层面(能源仪表)到过程层面(控制系统或紧凑型定制信息系统)MES层面(能耗分析和评估),横河电机提供一套整体能源解决方案,就好像是一个自动化金字塔

然而,在过程工业中,确定和实现工厂的潜在成本削减有四个基本条件:
1.一个数据量庞大且合格的数据库
2.智能数据分析和说明
3.清晰可视化结果
4.明确且有意义的行动方案

点击看大图


所有相关能源流的概述

目的是通过评估原始数据尽可能自动推导出最合适的能源使用方案然后以结构化形式将这些方案传达给相关操作人员。这是一个优势,用熟悉的流程图像解决工厂操作员的问题,并为他们提供容易理解的能量流概览。为了这个目的需要一个其他的指标,类似于Sankey中的箭头。

在多级菜单中提供了详细的补充信息。直观的配色方案清晰的屏幕布局和简单的图标使关键分析结果能够快速准确地被理解吸收。对于负责横河新的工厂能效管理系统PEEMS)的研发团队来说,易理解是首要被考虑的。

专用信息过滤器

企业决定运行EEM系统时,必须同时考虑当工厂扩和复杂增加时,EEM系统的扩展性。在极端情况下,一个基于记录仪的小系统可以逐步发展为使用独立PLC进行控制,并最终引入过程控制系统。EEM过程的结构 - 通常是能量优化操作的最重要手段 - 保持完整无缺,因此需要有意识的保留和扩展这种技术。

EMM系统不是取代工厂操作员的自动操作仪。相反,一系列其他参数,例如安全性原材料质量、特殊产品质量、生产效率和生产能力要求的可用组合都有着至关重要的影响。该系统就像是操作员辅助工具,集成以下重要功能:
1.比较趋势和能量优化操作
2.向工厂操作员显示,切换到不同的操作模式能节省多少能量
3.必要的时候,帮助操作员完成从现有操作模式到优化操作模式的转换

为了圆满完成这些任务,需要满足几个条件:可靠、有意义的数据库对数据的结构和优先级的说明,清晰且易于理解的可视化结果以及推荐一个或多个行动方案。

除了满足这些要求,横河电机的EEM系统可以最大限度地提高效率和降低成本,同时最大限度地减少工厂操作员的额外负荷

点击看大图





客户面临的挑战

流程工厂常常会使用几十年以上随着技术的发展革新,建设初期使用的自动化技术都会渐渐落后,这使工厂的业主浪费很多潜在的生产力。

我们的解决方案

我们在化学和制药行业的自动化经验超过40年,可以帮助您充分调动这些潜在的生产

成为现代化的工厂有很多益处

  • 不断增长的生产力和竞争力
  • 保护环境和自然资源的高效节能的生产流程
  • 切实以安全为导向,面向实际需要的
  •  用户友好操作
  • 通过横向和纵向整合提高信息透明度
  • 工厂资产的创新管理,提高工厂的效益
  • 更灵活的生产

在一定程度上,我们可以完成所有这些工作 - 保存已经实验和测定的内容,精确定位消除障碍优化结构通过模拟器进行虚拟工厂的培训,尽可能减少停机时间。

我们通过实施比较有效性分析来对旧的系统概念进行全面审查。使用我们自己的基准测试程序,从设计阶段开始,确定为工厂增加价值的最恰当的措施。

在风险分析的框架内,我们会尽快确定出现代化方面的关键指标,并根据状况有序实施计划措施。

点击看大图

使能技术

DIN EN 62402NAMUR NE 121的专业过时管理可以确保您获得可靠和可持续解决方案,在您工厂的整个生命周期内持续提供卓越的性价比。

使设备现代化不仅仅是升级。我们提供全方位的服务,无论是单独的设备还是整体工程的一部分,从最初的设想到工厂的运营,我们始终为您提供现代,高效的过程自动化。



概述:
  • Nan Ya had been using Yokogawa Micro-XL DCS since the plant opened in the 1990s.
  • Step-by-step approach for migration from Micro-XL to CENTUM VP keeps downtime to a minimum.
概述:
  • PRM allows a preventive maintenance approach where maintenance can be scheduled and performed before a field device fails.
  • Exaquantum gathers plant data from the CENTUM VP to generate a variety of reports on the polymerization process.
概述:
  • Exapilot is Effectively Applied to Polypropylene Plant and Optimizes Operation, Cost Savings.
  • By using Yokogawa's Exapilot, Safripol were able to eliminate product variations and kept the operations consistent.
概述:
  • Migration from Micro-XL and CENTUM CS 1000 to CENTUM CS 3000 Improves Reliability.
  • Operations at this plant, which runs more than 330 days per year, are carefully managed by the CENTUM CS 3000 DCS and the CS Batch package.
概述:
  • Highly reliable CENTUM CS 3000 replaces legacy system and automates batch plant operation.
  • Working together, Hanwha Chemical and Yokogawa Korea project personnel completed this work on time and on schedule.
概述:
  • Integration of CENTUM CS 3000 with ProSafe-RS improves plant safety and reliability.
  • Yokogawa's PRM package manages more than 500 HART field devices including control valves.
概述:
  • Fieldbus technology introduced to realize predictive and preventive maintenance.
  • ISAE to improve the reliability of diagnosis and parameter setting, utilizing data collected by PRM.
概述:
  • CENTUM CS 3000 and Exaquantum PIMS improve production efficiency at Chinese synthetic rubber plant.
  • Exaquantum provides data on long-term trends needed to make improvements to plant processes.
概述:
  • Based on a careful review of all operational procedures and operator roles and configured new SOPs in Exapilot.
  • As a result, SFC has been able to reduce operator workload, improve product quality, and reduce production losses.
概述:
  • The work was based on a preceisely formulated roadmap with detailed checklists for every control cabinet, process station, and network component.
  • The seamless use of the same HMI for both PCS and SIS, and improved safety and integrity.
概述:
  • CS Batch is used to automate a wide range of Reichhold's batch processes and multi-product/multi-path processes.
  • Using PRM, process engineers can immediately find out the status of every field device without having to do an onsite inspection.
概述:

Taiyo Nippon Sanso Corp. was looking for a system that could be easily adopted to its plant architecture. For the following reasons, Yokogawa's STARDOM system with the FCN autonomous controller and the VDS Web-based SCADA software was selected as their control system for a Water-18O plant and other facilities.

概述:
  • Installation of Exaquantum PIMS package improves efficiency of process data management.
  • Improve quality and yield through proactive maintenance of plant assets.
概述:
  • Exapilot was built up as e-SOP system based on the standard operating procedures and the know-how of experienced operators.
  • e-SOP system improved the quality and productivity in the performance chemical plant in China.
概述:
  • Easy-to-understand sequence programs' creation
  • An entire programming system built by operators
  • Operator workloads reduction
概述:

As the demand for food is increasing worldwide, fertilizers are playing an essential role in improving agricultural productivity. OCI Nitrogen (hereinafter OCI) is a leading producer of mineral fertilizers and the world's largest producer of melamine, which is used to make adhesives and resins for a wide range of applications, such as furniture panels, laminate flooring, coatings, paints, and plastics.

概述:
  • IFCo chose Omegaland operator training system to make ready for a flawless and safe plant start-up.
  • Omegaland is contributing to operator training prior to completion of the greenfield fertilizer plant.
概述:
  • Up to 90% of all manual tasks can now be carried out automatically.
  • Increasing productivity by means of partially automated start-up and load change procedures.
概述:
  • Yokogawa's CENTUM VP and PRM improve efficiency at new nylon plant in Thailand.
  • At the plant startup stage, PRM was used together with FieldMate to thoroughly check all loops.
概述:
  • At the company's Ulsan resin plant, six Exaquantum servers were connected to CENTUM CS 3000 and other vendor's systems.
  • KKPC needed to expand its SBC capabilities and improve production efficiency at its plants.
概述:
  • TOK decided to start local production of high-quality photoresist for semiconductor manufacturing near its customers in Taiwan.
  • The MES with traceability comparable with pharmaceutical manufacturing is one of the factors to win the trust of its customers.
概述:
  • FDT compliant FieldMate manages a wide variety of digital process instruments of multi-vendors.
  • The SNF engineers can manage the complete lifecycle of assets and configure devices by using FieldMate.
概述:
  • Kuraray EVAL and Yokogawa prepared carefully for the expansion and modernization of the CENTUM system.
  • Management of 400+ fieldbus instruments by Yokogawa's PRM plant resource manage also helped the project to proceed smoothly.
概述:

The UT series of temperature controllers is perfect for controlling the heating temperature of sealing parts and the temperature of sealing rolls (pre-heating) in a variety of different wrapping machinery.

概述:

This introduces a system that uses Ethernet communications to acquire measured values, target values, and control output values from a controller installed on site into a PLC at high speed (ten units' worth within one second).

概述:

In the plants of food and beverage manufacturers, there are times when monitoring and recording of production equipment is necessary inside clean rooms. This is an introduction to monitoring and recording in clean rooms using paperless recorders.

概述:

The ADMAG AXR is the world's first 2-wire magnetic flow meter which employs the unique "Dual Frequency Excitation Method," achieving 0.5% of rate of best-in-class accuracy and excellent stability for process measurement. In addition, the newly developed AXR key technologies," achieves the same level of noise immunity as 4-wire type under the fluid condition change and delivers enough performance to meet the requirement to apply in the control loop.

概述:

Control of sodium chloride (NaCl) concentration at a salt dissolver where solid salt is dissolved in water, is highly important because of the electrolysis efficiency. A conventional way of measuring the concentration of supersaturated NaCl solution had been performed by using non-contact type sensors (e.g., γ-ray density meter) since NaCl, impurities, and precipitates are in the solution.

概述:

In the manufacturing process of Pharmaceutical, Chemical and Food & Beverage industries, the cleaning and sterilization of tanks and piping are done with various cleaning solutions, fresh or hot water and steam after manufacturing products. Clean-In-Place (CIP) is the system designed for automatic cleaning and disinfecting.

概述:

There are various methods for continuous fabric dyeing as well as dye fixing. When dye is directly applied, steaming (heat treatment) is required. At present the pad-steam method is widely used for continuous dyeing. To ensure stable product quality, the humidity in the steamer is kept at a constant level.

概述:

In flue gas desulfurization systems that use magnesium hydroxide (Mg(OH)2) slurry, the consumption of the desulfurization agent (Mg(OH)2) is controlled by using online pH analyzers. A great concern in the pH measurement is heavy staining of the pH electrodes by the Mg(OH)2 slurry. To ensure accurate measurement, frequent cleaning of the electrodes with an acid is required, adding to both maintenance workload and cost.

Industry:Chemical, Power

概述:

Recently, air pollution legislations such as the Clean Air Act to reduce the amount of air pollution are increasing worldwide. The Clean Air Act address numerous air quality problems. One of these problems is acid rain caused by sulfur dioxide and nitrogen oxide emissions from fossil-fueled power plants and other industrial and transportation sources.

概述:

Caustic soda is an important basic material in the chemical industry and is mainly produced by the electrolysis of soda. In the electrolysis process to make concentrated caustic soda, the DM8 Liquid Density Meter ensures high product quality through accurate measurement of liquid density.

概述:

One of the most common applications for differential pressure transmitters is flow measurement. DPharp differential pressure transmitters have some unique signal conditioning features to eliminate instability at low flow rates.

概述:

Process liquid analyzers such as pH meters, conductivity meters, ORP meters, and density meters play an important role at electrolysis plants in the control of concentrations of various process solutions. This requires both precision and stability under harsh conditions that include highly corrosive substances, high temperatures, and many impurities.

应用
概述:

Level transmitter configuration can be very time consuming. DPharp transmitters with advanced software functionality eliminate this time consuming task. With maintenance shops getting smaller, finding equipment that allows us to do more with less becomes a priority.

概述:

Many different types of gases are consumed in industries as varied as chemicals, food & beverages, and medical. These gases are normally delivered in liquid form by trucks and dispensed at the customer site. Although the flow volume of cryogenic liquefied gas is used for billing purposes, it is not easy to accurately measure this because the gas is always at saturation temperatures.

概述:

The CX1000/CX2000 offers an average value computation function making it ideal for controlling temperature and other fluctuating phenomena. The operating status can be controlled in real time, providing operating cost reductions.

概述:

Reverse osmosis (RO) is a separation process that uses pressure to force a solution through a membrane that retains the solute on one side and allows the pure solvent to pass to the other side. More formally, it is the process of forcing a solvent from a region of high solute concentration through a membrane to a region of low solute concentration by applying a pressure in excess of the osmotic pressure.

概述:

The discharge of improperly treated industrial chemicals and fuel gas can have a major impact on the environment, posing a serious threat to public health. Concurrent with the global growth of manufacturing operations to keep pace with market trends, many countries are taking measures to deal with environmental problems.

概述:

Controls temperature in, and acquires data from, various internal components of plastic film manufacturing equipment. An easy to use, high cost-performance data acquisition and monitoring system can be assembled by using Ethernet compatible instruments and DAQWORX package software.

概述:

Industrial Combustion sources such as thermal cracking furnaces and, process heaters play a critical role in the process industry.

概述:

In limestone-gypsum flue gas desulfurization systems, the consumption of a desulfurization agent (lime) is controlled using online pH analyzers.

概述:
  • Compressor start and stop
    The inlet valve and blow-off valve are controlled efficiently.
  • During steady-state operation
    The inlet valve is controlled to regulate the blow-off flow rate of the compressed air. (Flow control)
概述:

For safe and efficient operation, the quality of feedwater, steam, and condensate in boiler plants must be controlled and maintained in the most favorable conditions.

概述:

Industrial Combustion sources such as thermal cracking furnaces and, process heaters play a critical role in the process industry. Because the large amount of fuel such as gas or fuel oil which is consumed in these processes, their combustion efficiency directly affects the performance and operational costs of the production facilities.

概述:
  • In the YS170 and SLPC, single-element control needs to be configured within the user program.
  • The YS1700, however, offers the primary direct mode so that the user program can switch on and off single-element control by changing a parameter.
概述:

Operators must receive diagnostic information before a line block leads to a malfunction. Yokogawa provides predictive diagnostics based on trend analysis of the blocking factor, which improves maintenance efficiency and reduces maintenance costs.

概述:

Steam is still one of the most popular methods of providing an energy source to a process and its associated operations. The more accurate and reliable measurements that are made, the more informed decisions can be taken that affect costs and product quality.

概述:
  • Emergency interlock circuits for petrochemical plants and other facilities must be independent of the main control system.
  • The YS80 Rack Instrument interfaces not only with field devices and upstream control systems, but also with emergency interlock circuits guarding against process abnormalities.
概述:

The DXAdvanced Paperless Recorder (hereinafter, the DX) lets you write arbitrary messages on the trend display screen that are useful for writing comments or memos. Moreover, with a combination of the DX touch screen model (DX1000T/2000T) and the custom display function, you can write messages, start/stop recording, and perform a variety of other tasks at the touch of a button.

概述:

In the course of more than twenty years as an engineer involved directly in utility related projects in a number of industries, I have seen a great variety of energy efficiency projects and programs covering the entire spectrum of efficacy. The Deer Park, Texas, plant of the Rohm and Haas Company has a unique energy management program that has proven to be highly successful. This program has resulted in a 17 percent reduction in energy use on a per pound of product basis, saving 3.25 trillion btus and $15 million each year! This article discusses this program, its history, successes, and the unique characteristics that have contributed to those successes.

概述:

The REPSOL company had in mind the improvement of the control on one of their chemical reactors. A feasibility study for the implementation of an Advanced Control technique (Predictive Control for temperature control for chemical Reactors - PCR) for a batch reactor for Polyols production has been performed. The proposed technique PCR is based on a dynamic model of the unit which makes the prediction of the process variables behaviour.

概述:

After a feasibility study, Repsol YPF decided to apply a model-based predictive controller to a batch reactor producing polyols. The predictive controller for reactors (PCR) is a set of control modules that are designed to face most of the reactor configurations. The important increase of production is a consequence of the better handling of the reactor temperature. Here's a description of the unit and control objectives, methodology, project steps, results and the corresponding benefits.

概述:

From engineering to installation, commissioning, operations, and maintenance, FOUNDATION fieldbus offer significant cost reductions of 30 percent or more versus conventional analog systems. Many of these cost reductions come from the advanced functions that fieldbus offers versus analog technology.

概述:

The automation suppliers that will be successful in the long term will be those that effectively address application or industry specific problems for end users with a value proposition that cannot be ignored. These problems exist throughout the process industries today, and they won't be solved by simply offering a product, but through a combination of hardware, software, services, application expertise, and knowledge.

概述:

In ARC's view, customers need a compelling business value proposition to justify investment in any kind of automation. Vigilance and VigilantPlant were created with this in mind. Yokogawa's vision with VigilantPlant is to create an environment where plant personnel and operators are well informed, alert, and ready to take action.

概述:

Yokogawa has come a long way in making its message clear to the world of process automation. Last year, the company embarked on a full-scale global marketing campaign to make customers aware of the company's focus on system reliability, security, dependability, and robustness. Dubbed "Vigilance", the campaign created a unified message for the company and greatly helped expand awareness of the Yokogawa brand and corporate philosophy.

概述:

Process automation end users are under more pressure than ever to do more with less. The current economic climate means that many automation capital projects are on hold. With capital budgets tighter than ever, users instead focus on operational budgets (where cost cutting is also a key concern), or on automation investments with a very rapid return on investment.

概述:

In today's dynamic industrial marketplace, the only constant is change. Raw material costs, energy costs, market demands, environmental and safety regulations, technology, and even the nature of the labor force itself are constantly changing, and not always in predictable directions.

概述:

September 2008

Yokogawa is helping a large chemicals site in China manage product transfer by road, ship and pipeline.

概述:

ISA S88.01 provides great benefit to users and vendors by solidifying batch operating models and standardizing batch control terminology. On the other hand, as befits an industry-wide standard, ISA S88.01 leaves great flexibility for individual users to apply their own project practices and implementation methodology. Even when utilizing ISA S88.01 models and terminology, many pitfalls remain for those who implement batch controls and recipe management without thinking ahead. Real-world project experience has demonstrated a number of design and implementation "lessons" which might be overlooked to the eventual grief of the batch engineer.

概述:

The S88.02 draft standard defines a means for depicting procedural control in master and control recipes. This depiction method is called a Procedural Function Chart (PFC). This standard depiction is based on the requirements of S88.01, technical report ISA-TR88.0.03-1996, user requirements, previous standards and commonly used procedure depiction methods in use today. PFCs can provide a common basis for the exchange of recipes, reduce the learning curve between control systems, and establish a common ground for improved human communication. This paper provides a brief overview of the development of PFCs, the rules for their use and some of the benefits expected by their adoption in the industry.

概述:

The case study in this paper illustrates the value of integrating front-end scheduling with a batch control system. Recipe changes, and addition of recipes, occur frequently in the target process. However, since both scheduler and batch packages were designed with the ISA-S88.01 model in mind, these packages could be tightly coupled (well integrated) – and, as a result, it is easy to add or change recipes. The front- end scheduler is not limited to performing scheduling; it also provides an easy-to-grasp real-time production status display which can help enhance efficiency and productivity.

概述:

As batch processes are automated, it is common to leave certain less essential field devices without automatic actuators. Thus, the initial control design must accommodate both automated and manual activities. Later, the manual field devices may be automated, either one-at-a-time or in related groups as equipment modules. These field changes, often occurring over a period of years, each require rework of the batch control logic, which can easily exceed the cost of the actuator. In response to this undesirable situation, a technique has been developed which permits the batch design to automatically modify itself, or evolve, to accommodate changes in field automation.

概述:

Six Sigma is a quality improvement methodology applied to improving any type of process. It is a methodology endorsed by and heavily integrated into several major chemical companies.

概述:

Key Performance Indicators (KPIs) are used in batch processing industries as measurements of production performance. Their use is one element in the current trend of real-time performance management. A single KPI used as the primary measurement of production can cause other dimensions of production performance lose importance. When multiple KPIs are used to measure a batch's production performance it can be difficult to reconcile differences between them for individual batches or for groups of batches. KPIs based upon meeting a target, or specification, measure absolute performance yet do not provide relative information regarding how a batch performed against its peers. The peer comparisons are important for monitoring variability of production performance, which is a critical factor in documenting ROI.

概述:

The application of DCS-based "advanced controls" is a common method of achieving enhanced performance from continuous processes such as refinery units. However, it is less widely recognized, but nonetheless true, that modern DCS systems can include other software tools for the significant improvement of batch plant productivity, product quality, and economic performance. Due to the fundamental processing differences between the two types of plants, unique batch "advanced control" features are required which are different from those used for continuous plants.

概述:

ARC believes that by implementing procedural automation, many process plants can minimize variability to help ensure smooth, efficient, and safe state transitions.
