LNG供应链

在20世纪70年代,横河电机承诺对全球LNG项目进行革新。 凭借着丰富的经验和与解决方案方面的结合,横河电机具备实现LNG供应链卓越运营条件。

  • LNG液化

    36%的液化厂使用横河电机的DCS
    39%的液化厂采用横河电机的APC解决方案。

    更多
  • LNG运输船

    66艘运输船使用了横河的DCS。凭借着自身的行业经验横河电机提供可满足海洋作业需求的解决方案。几十年来,横河电机一直向全球多家LNG运输公司提供IAS。通过对整个生命周期的支持,我们为长期合作的伙伴提供资产价值的最大化。

    更多

挑战

将新技术和经过验证的技术结合,提高HSE性能

客户面临的挑战

横河电机拥有超过45年的LNG项目经验,具有丰富的工程专业知识。 我们可以在不中断城市燃气生产的情况下更换控制系统,确保迁移路径无缝连接、提供全方位的实施服务

投资范围从传统的大型项目,扩展到了小型项目和海上设施。 对于这类任务,必须将新技术和经过验证的技术相结合,并且力争在健康、安全、环境(HSE)方面取得进步。

我们的解决方案

横河凭借在LNG供应链方面深厚的专业知识,针对更宽范围的HSE方面提出并实施新的解决方案。我们的解决方案能够在早期阶段进行无间隙LNG泄漏检测、监控以及检测干扰。 横河还可以协助将经过验证的陆上技术集成到浮式储存、再气化装置(FSRU)、浮式LNGFLNG)设施以及LNG船舶上。

使能技术

集散型温度传感器:DTS
横河电机DTSX3000和DTSX200可实现无间隙LNG泄漏检测监控。



快速准确地响应需求的变化

客户面临的挑战

横河电机拥有超过45年的LNG项目经验,具有丰富的工程专业知识。 我们可以在不中断城市燃气生产的情况下更换控制系统,确保迁移路径无缝连接、提供全方位的实施服务。

LNG供应链环节的主要挑战是快速准确地响应需求的变化。这既是对客户的承诺也是合同规范的要求。任何LNG设施在开始商业运营之前,确定基本的工厂KPIs并建立标准化的人工干预程序是非常重要的。

我们的解决方案

装载、卸载、冷却、补充制冷剂循环(RC)、以及其他非常规操作都会对LNG设施的稳定性产生重大影响。基于横河电机在LNG领域的长期经验,我们的解决方案可以帮助您顺利执行这些主要操作。Exapilot是一种直观且易于使用的导航工具,可为操作员提供确保顺利执行非常规操作所需的提示。横河电机的工厂信息管理系统Exaquantum可以从集散型控制系统(DCS)获取过程数据,将其转换为必要的KPI,并在必要时根据KPIs自动生成报告及时上传给DCS

使能技术

生产控制系统:CENTUM VP
单一综合控制和安全系统(ICSS)数据库简化了工程设计。图片、报警窗口、系统状态显示都具有相同的外观和感觉,操作也更容易。


安全仪表系统:ProSafe-RS
取得安全完整性等级1-4SIL1-4)认证的ProSafe-RS安全仪表系统的高可用性,实现了真正的集成化解决方案。


提高操作效率:Exapilot
Exapilot是一种在线导航工具,可指导操作员逐步完成工厂操作程序。


工厂信息管理系统:Exaquantum
生产管理解决方案可以让所有资产性能的可见性得以实时体现,以促进智能决策。



处理气体成分的变动

客户面临的挑战

横河电机拥有超过45年的LNG项目经验,具有丰富的工程经验。 我们可以在不中断城市燃气生产的情况下更换控制系统,确保迁移路径无缝连接、提供全方位的实施服务。

来自不同地方天然气的成分通常不同,预计这种差异性在未来几十年内还会加大。 因此,接收终端需要应用最佳的实践经验,并且在整个工厂生命周期中处理这种变化带来的影响。

我们的解决方案

横河电机的先进过程控制(APC)解决方案在液化和再气化过程中发挥着不可或缺的作用。在液化过程中,APC解决方案优化了热交换器(HE)和制冷剂循环(RC)之间的相互作用,实现了高效的无热应力操作。再气化过程中,APC解决方案允许根据沃泊指数值和气体蒸发(BOG)的容积和时间进行最佳的分配和指派,从而防止产生不合格气体。此外,通过综合控制和安全系统(ICSS)和高精度过程模拟(操作员培训系统OTS)进行全面仿真,不仅需要衡量改变操作的效果,还有助于HSE指标的整体评估。

使能技术

操作培训系统:OTS

OmegaLand为操作员培训DCS和安全系统提供虚拟的工厂模拟环境。

OmegaLand是横河集团的子公司Omega Simulation 公司的产品。


APC 产品: Exasmoc, Exarqe, Exacoast
横河电机可以优化HERC之间的交互影响,实现高效的无热应力操作。



详细介绍

生产控制系统:CENTUM VP

单一综合控制和安全系统(ICSS)数据库简化了工程设计。 图片、报警窗口、系统状态显示都具有相同的外观和感觉,操作也更容易。

安全仪表系统: ProSafe-RS

取得安全完整性等级1-4SIL1-4)认证的ProSafe-RS安全仪表系统的高可用性,实现了真正的集成化解决方案。关于上游过程包括井口和管道的连接性,我们已经在Vnet / IP实时控制总线和专用于上游过程的单一网络上实现了ProSafe-RSSTARDOMFAST / TOOLS SCADA系统之间的连接。因此,FAST/TOOLS现在可以用一种集成方式监视STARDOMProSafe-RS系统。

现场仪表

数字现场仪表可提供稳定、精确的过程测量,安装成本低,零维护,并有智能自诊断功能。作为现场总线技术的领头羊,横河电机将基于FOUNDATION Fieldbus™的设备推向市场,并开发了全系列的FOUNDATION Fieldbus™现场仪表。

分析仪

快速响应的分析系统通过提高英国热量单位(BTU)测量的准确性和优化锅炉燃烧来确保严格的质量控制。

流量计算机

STARDOM符合美国天然气协会(AGA)标准气体量的计算。

操作培训系统

OmegaLand为操作员培训集散型控制系统DCS和安全系统提供虚拟的工厂模拟环境。

生产管理

生产管理解决方案可以让所有资产性能的可见性得以实时体现,以促进智能决策。

先进过程控制

先进过程控制(APC)可将液化装置的吞吐量提高0.5-2%,并将能源成本降低1-3%。

工厂资产管理:PRM

工厂资源管理(PRM),使预测性维护变得方便容易。可以尽早发现系统和设备故障可以有效防止灾难性故障的发生。



参考

概述:
  • World's largest LNG terminal relies on CENTUM to maximize safety and reliability.
  • It is very important for KOGAS to be able to adjust flexibly to shifts in demand in the gas that it supplies to power plants, industrial companies, and residences.
概述:
  • DCS, SIS, PRM with FOUNDATION fieldbus and OTS Installed in Thailand First LNG Terminal.
  • Alarms are issued before any device fails completely, enabling predictive maintenance that reduces maintenance costs throughout the facility lifecycle.
概述:
  • Yokogawa provides CENTUM CS 3000 and ProSafe-RS for the largest LNG terminal in Europe.
  • Yokogawa's OmegaLand plant operator training simulator (OTS) helps to reduce costs, optimize LNG terminal processes.
概述:
  • OTS for familialization of liquefaction processes and operator training.
  • Yokogawa's integrated solutions contribute to safe and steady production at gas liquefaction plant in Norway.
行业:
概述:
  • World's first offshore regasification terminal relies on Yokogawa ICSS (CENTUM CS 3000, ProSafe-RS).
  • LNG carrier scheduling, unloading, tank storage, and vaporizing are all procedure based operations.
概述:
  • CENTUM CS 3000 ensures safe and reliable operation of one of the world's most advanced LNG carriers.
  • Yokogawa successfully installed a CENTUM CS 3000 integrated control automation system(ICAS).
行业:
概述:
  • MISC could be ensured of better information visibility, performance foresight, and operational agility.
  • Yokogawa CS 3000 system has proven in both the Tenaga and the Seri Class LNG carriers that their hardware is very reliable with very less problem.
行业:
概述:
  • Legacy ProSafe-PLC SIS replaced with ProSafe-RS to improve sustainable lifecycle support at LNG terminal.
  • The seamless use of the same HMI for both PCS and SIS, and improved safety and integrity.
概述:
  • Scalable, flexible configuration with functions distributed to multiple controllers on a facility basis
  • Redundant architecture optimally designed for requirements of entire plant
  • General-purpose communications network used for control bus
  • Integrated operation environment through web-based human-machine interface (HMI)
概述:
  • A phased upgrade approach from CENTUM CS to CENTUM VP was planned to meet tight LNG carriers schedules.
  • The collaboration using CENTUM VP and APC provides optimization of gas liquefaction operation.
行业:
概述:
  • Operator training system for the critical LNG processes had been built to reduce human errors and achieve operational excellence.
  • The high fidelity modeling of LNG liquefaction process closely matches the behavior and operational environment of the actual plant.
行业:
概述:
  • Hibiki LNG Terminal is supplying natural gas to a broad area of northern Kyushu.
  • CENTUM VP and FA-M3V provide a centralized monitoring environment and contribute to safe and stable operation.
概述:

An automatic custody transfer system for unmanned LNG gas stations that embeds PC oriented functions such as e-mail, FTP, and the Java runtime environment in a robust hybrid controller.

概述:

With industrial and economic development comes increasingly large and advanced power plants and factories. Nevertheless, we find many cases where the original cables, cable tunnels, and other components of the power infrastructure have languished under continuous operation.

概述:

Recently, several ARC Advisory Group analysts and management team members had a chance to sit down with the new Yokogawa President and COO, Mr. Takashi Nishijima, and several other top Yokogawa executives to discuss the company's burgeoning presence in the worldwide upstream and midstream oil & gas industry.

概述:

Over the past decade, companies have been using unconventional drilling technology to extract gas and liquid from the readily available shale formations in North America. As the industry gains experience, the production rates continue to rise based on better use of technology to locate resources and to decrease the time from exploration to production.

概述:

As LNG moves from a niche to a major area of the oil and gas industry, experienced suppliers are required to deliver the technologies that support it.

概述:

Only 5% of data is transferred into meaningful information so, asks Frank Horden, Business Development Manager, Yokogawa Global SCADA Center, USA, how to ensure pipeline management data is translated into valuable knowledge?

概述:

July 2010

Martin te Lintelo, Yokogawa Europe B.V., The Netherlands, discusses high level control system design for LNG receiving terminals. As demand for LNG increases worldwide, players face seemingly conflicting challenges. On one hand, they must expand capacity in different regions, make the business and production as agile and adaptive as possible, and improve operational efficiency.

概述:

The LNG sector presents challenges for the automation supplier, particularly in the implementation of automation systems for regasification terminals. Yokogawa Europe's business development manager, upstream oil and gas Martin te Lintelo looks at the handling of the potential automation-related problem areas and opportunities.

概述:

Platt Beltz and Greg Hallauer, Yokogawa, USA, discuss how simulation can improve operator training in LNG operations.

概述:

LNG Industry, Summer 2012

Martin te Lintelo, Yokogawa, The Netherlands, discusses the need for better automation, measurement and control instruments to cope with the rising popularity of LNG.

行业:

下载

视频

概述:

DTSX has been increasingly used in variety of applications such as fire detection, leak detection and preventative maintenance.

概述:

As a gateway to further expand Yokogawa's messaging as a One-stop Solution Business, Yokogawa has partnered up with INCIT, to introduce the S.I.R.I. framework.

概述:

Yokogawa South Africa was appointed to design, supply and commission the Integrated Control and Safety System (ICSS) as well as the overall Terminal Management System at Sunrise Energy’s liquid petroleum gas (LPG) Import Terminal, the largest on- and offshore open-access LPG import terminal facility in Africa. Yokogawa’s Terminal Management System, Terminal Logistic Suite VP (TLSVP), was designed and developed to meet the exacting operational demands and logistic needs in terminals. Yokogawa’s experienced engineering resources ensured the project was successfully delivered, enabling Sunrise Energy to provide accurate mass balances and efficient terminal operations to its customers.
