挑战
客户面临的挑战
防止在腐蚀性环境中使用设备时发生的腐蚀
我们的解决方案
进入横河电机综合生产控制系统的印刷电路板均采用耐硫化氢涂层,并且所有横河电机现场设备均采用防腐蚀涂层。
使能技术
EJX/EJA系列差压/压力变送器
数字压力变送器的DPharp系列使用了差压高精度谐振(DPharp)传感器,代表了变送器技术中革命性的进步之一。
YTA系列温度变送器
YTA系列温度变送器将传感器输入转换为4~20 mA的HART或FOUNDATION™现场总线信号,消除了传统温度仪表经常遇到的接线电阻和信号干扰的缺点。
无线变送器:EJX B系列、YTA510、YTMX580
无线解决方案的灵活性降低了基础设施成本,并使变送器能够安装在先前接线过于困难或过于昂贵的位置。
FLXA21模块化2线制液体分析仪
FLXA21是新一代模块化液体分析仪,可灵活配置用于测量pH/ORP、接触电导率、感应电导率和溶解氧。FLXA21还可以安装两个相同类型的传感器,从而降低安装成本并节省空间。
PRM工厂资源管理器
工厂资源管理器(PRM)使预测性维护变得容易。对系统和设备故障进行早期检测有助于防止灾难性故障。
客户面临的挑战
对距离地热发电厂相当远的蒸汽井和回注井等设施进行可靠地远程监测和控制
我们的解决方案
横河电机安装远程I/O模块,并采用光纤冗余环形拓扑结构,以确保综合生产控制系统和现场设备之间的可靠通信。无线现场设备用于难以接线的位置。
使能技术
STARDOM基于网络的控制系统
STARDOM混合PLC/智能RTU提供双冗余和低功耗配置。STARDOM支持HART、Modbus、FOUNDATION™现场总线和其他网络协议。
FAST/TOOLS SCADA
FAST/TOOLS软件包可以为可再生能源应用优化性能。确保了高可用性和性能,并支持在线配置。
无线变送器:EJX B系列、YTA510、YTMX580
无线解决方案的灵活性降低了基础设施成本,并使变送器能够安装在先前接线过于困难或过于昂贵的位置。
客户面临的挑战
有效地维护距离地热发电厂相当远的设备
我们的解决方案
横河电机的工厂资源管理器(PRM)是一个综合设备管理软件包,可以远程监测设备的状态并更改其设置,从而提高维护效率。这很大限度地减少了工人在地热站点进行故障排除和其他任务所需的时间,从而更大限度地减少了他们暴露于硫化氢气体的危险,硫化氢气体的浓度足够高,可能会带来健康风险。
使能技术
PRM工厂资源管理器
工厂资源管理器(PRM)使预测性维护变得容易。对系统和设备故障进行早期检测有助于防止灾难性故障。
CENTUM VP综合生产控制系统
CENTUM VP综合控制系统可确保无中断的“仅限正常运行时间”的工厂性能,从而在可再生能源领域中实现较高的生产率和盈利能力。
STARDOM基于网络的控制系统
STARDOM混合PLC/智能RTU提供双冗余和低功耗配置。STARDOM支持HART、Modbus、FOUNDATION™现场总线和其他网络协议。
FAST/TOOLS SCADA
FAST/TOOLS软件包可以为可再生能源应用优化性能。确保了高可用性和性能,并支持在线配置。
详细介绍
地热发电过程
蒸汽井用来从地下深处的地热储层中抽取由蒸汽和热水组成的流体。将流体混合物引入蒸汽分离器,从蒸汽中除去水分,蒸汽则用于驱动发电机的涡轮机。涡轮机排出的低温蒸汽通过蒸汽冷凝器使水蒸气返回到液态,然后通过回注井将水返回到地下储层。
控制和测量技术
全厂系统和仪表 | ||
---|---|---|
信息
|
控制
|
测量
|
过程 | ||
液体运输 | 主地热发电 | 涡轮机 |
|
|
|
