Thermal Management System

Yokogawa's thermal management system provides a ready-to-install solution for applications ranging from basic temperature control to highly complex part curing ovens. Utilizing Yokogawa's proven, best-in-class hardware and engineering expertise, this unique solution delivers a true turnkey package for a wide range of applications.

Complete Turnkey Control Solution

Systems can be designed and built to customer-specific applications and requirements. The system arrives pre-configured, programmed and ready to run. Installation is simple: mount the enclosure, land the field wiring, apply power, and run.

Features & Benefits


  • The Yokogawa AXON Thermal Management system meets or exceeds all AMS2750 Rev. E applicable requirements regarding measurement and control, as well as data generation and storage.

Ease of use for operators

  • Intuitive, easy-to-read screens
  • Operators can quickly learn how to operate the system through quick and simple navigation

Data logging for all test readings

  • Logging is active during recipe runs
  • Logged data is stored internally in the recording unit on industry standard media
  • When recipe run is completed, the data files can be automatically FTP’d to a server or other PC for analysis, report generation and archive

Easy to load recipes for multiple product runs

  • Allows development and management of multiple product recipe runs
  • Recipes can be created locally and saved on a separate server, then easily re-loaded into the system locally or remotely

Maximum control options

  • All production systems can be locally or remotely viewed and controlled
  • Overdrive function
    - For parts curing and other applications utilizing multiple T/C’s for overall temperature compliance, the overdrive feature eliminates the need for multiple controllers - a single tuning sequence for the system is all that is required
  • Vacuum control
  • Carbon potential

Best in class temperature control

  • T/C correction functions
  • Temperature control module enables fine control at high speed, accuracy, and resolution
  • Built-in “SUPER” function surpasses overshooting using fuzzy theory and a “dynamic auto-tuning” function to deliver the best possible manufacturing quality


Main Menu

Control Screen


Control Screen

Report Screen
