Yokogawa는 수처리 설비의 더욱 안정적인 운영을 위한 최적의 솔루션을 제공합니다. 이러한 솔루션에는 정교한 기술, 탁월한 제품 품질 및 라이프 사이클 전반에 걸친 광범위한 애플리케이션 노하우가 포함됩니다.
안정적인 수자원 공급을 위해 바닷물 담수화에 대한 수요가 증가하고 있습니다. Yokogawa는 RO (Reverse Osmosis), MSF (Multi-stage flash) 및 MED (Multi-effect distillation)와 같은 다양한 유형의 담수화 플랜트 제어에 대한 풍부한 경험을 보유하고 있습니다.
파이프라인은 특히 급속한 산업화와 인구 증가를 겪고 있는 건조한 지역의 수원에서 물을 운송함으로써 중요한 역할을 합니다. Yokogawa는 600km에 이르는 거리에서 파이프라인 제어 솔루션을 제공하고 있습니다.
수도망에 대한 한 가지 중요한 문제는 배관에서 물이 새는 것입니다. Yokogawa는 수도망의 손실을 최소화하기 위해 손실 관리 솔루션을 제공하여 낭비되는 물을 줄입니다.
폐수 처리 설비는 많은 모터, 펌프, 송풍기 등을 사용하기 때문에 운전 비용을 줄이기 위해서는 전력 소비를 줄이는 것이 중요합니다. Yokogawa는 에너지 효율성을 높이기 위한 최적의 제어 솔루션을 제공합니다.
공업용수는 발전소, 정유소 및 석유 화학 플랜트와 같은 모든 산업 플랜트에 사용됩니다. Yokogawa의 단일 제어 플랫폼은 주요 공정과 통합된 모든 용수 및 폐수 처리 공정을 처리할 수 있습니다.
안정적이고 신뢰할 수 있는 전체 프로세스 운영
Yokogawa의 산업 자동화에 대한 투자는 플랜트의 효율성과 생산성을 단계적으로 향상시키는 시작일 뿐입니다. Yokogawa의 제어 및 계측 솔루션은 수처리 운영의 핵심 요소로서 전체 프로세스에서 안정적이고 신뢰할 수 있는 운영을 보장합니다.
관리 솔루션 패키지
아래의 Yokogawa 관리 솔루션 패키지는 플랜트 운영과 관련하여보다 안전하고 안정적이며 최적화되고 효율적인 플랜트 운영에 대한 혜택을 제공합니다.
"Exapilot" 운영 효율성 개선 패키지, "Exaplog" 이벤트 분석 패키지, "Exaquantum" 플랜트 정보 관리 시스템, "PRM" 플랜트 자원 관리자, 물 손실 관리 시스템 등.
Full-scale 산업 플랜트의 제어 및 운영
공업용수 공급 업체는 산업시설 수요의 요구 사항을 충족시키기 위하여 최근 산업 용수 공급뿐만 아니라 증기, 전기, 폐수 처리 및 재활용에 대한 제어 범위를 확대하고 있습니다.
최첨단 아키텍처로 신뢰성이 높은 CENTUM VP는 업계의 다중 유틸리티 플랜트 전체를 모니터링하고 제어할 수 있는 포괄적인 DCS 솔루션의 핵심 플랫폼입니다.
광역 SCADA/PLC 제어 솔루션
STARDOM 및 FA-M3V는 개방적이고 강력한 PLC/RTU 시스템으로 넓은 지역에 분산된 다양한 정수 및 폐수 시설을 제어할 수 있습니다.
STARDOM 및 FA-M3V는 SCADA 시스템 "FAST/TOOLS" 및 Yokogawa의 관리 솔루션 패키지와 함께 높은 가용성, 대규모 확장성 및 효율적인 생산으로 최대의 수익을 가져다줍니다.
Wireless Innovation으로 플랜트 개발
Yokogawa의 지능형 필드 장치는 디지털 라이프 사이클을 단순화, 유지 및 관리할 수 있는 선도적이며 신뢰할 수 있고 상호 운용 가능한 솔루션을 제공하여, 수처리 산업의 현재와 미래의 요구를 충족시킵니다.
필드 디지털 솔루션은 EJX 시리즈 압력 전송기와 같은 현장 계기의 고급 진단 기능과 함께 사용하여 상호 운용성을 보장합니다.
총 소유 비용(Total Cost of Ownership) 절감을 위한 액체 분석기 및 레코더
Yokogawa는 고품질의 정확하고 신뢰성이 높은 제품의 광범위한 액체 분석기와 레코더를 제공해왔습니다.
이 모든 제품들은 총 소유 비용을 줄일 수 있도록 최대의 정확성, 안전성, 안정성 및 신뢰성을 제공하도록 설계되었습니다.
