바이오매스 발전

바이오매스는 최근 화력 발전소가 이산화탄소 배출량을 줄일 수 있는 재생 가능 에너지원이기 때문에 점점 더 이슈가 되고 있습니다. Yokogawa 시스템은 바이오매스를 사용하는 발전소를 포함하여 모든 유형의 발전소에서 전 세계적으로 사용되고 있습니다. Yokogawa의 측정 및 제어 기술을 통해 발전소는 보다 효율적으로 운전이 가능하며 탄소배출을 줄일 수 있습니다.

Challenges

Customer Challenge

발전소 효율 향상

Solution

Yokogawa는 연료, 스팀 및 급수 제어를 개선하여 발전소가 보다 효율적으로 운전할 수 있도록 지원하고 있습니다.

Enabling Technologies

CENTUM VP

CENTUM VP Integrated Production Control System

CENTUM VP 통합 제어 시스템은 재생 가능 에너지 분야에서 최적의 생산성과 수익성을 위한 중단 없는 "Uptime 전용"시스템 성능을 보장합니다.

* Uptime : 가동시간


Exapilot

Exapilot Operation Efficiency Improvement Package

Exapilot은 운영자가 공장 운영 절차를 단계별로 안내하는 온라인 내비게이션 도구입니다. Exapilot은 표준 운전 절차 (SOP)를 자동화하고 프로세스 및 장치 이상을 조기에 감지합니다.



Customer Challenge

안전하고 효율적인 보일러 가동

Solution

Yokogawa 시스템은 연료 가열 및 바이오 매스 연료로 전환과 같은 프로세스를 자동화함으로써 플랜트를 보다 안전하고 효율적으로 만듭니다. 그래픽 디스플레이를 통해 운영자는 각 프로세스의 상태를 실시간으로 확인할 수 있습니다.

Enabling Technologies

CENTUM VP

CENTUM VP Integrated Production Control System

CENTUM VP 통합 제어 시스템은 재생 가능 에너지 분야에서 최적의 생산성과 수익성을 위한 중단 없는 "Uptime 전용" 시스템 성능을 보장합니다.

* Uptime : 가동시간


Exapilot

Exapilot Operation Efficiency Improvement Package

Exapilot은 운영자가 공장 운영 절차를 단계별로 안내하는 온라인 내비게이션 도구입니다. Exapilot은 표준 운전 절차 (SOP)를 자동화하고 프로세스 및 장치 이상을 조기에 감지합니다.


Simulator

Simulator

High Fidelity, Full-replica Training Simulators



Customer Challenge

연소 효율 개선 및 유해한 스택 배출물 감소/제거

Solution

Yokogawa 산소 분석기는 연도 가스의 산소 (O2) 농도를 측정합니다. 이 정보를 사용하여 공연비를 조정하여 연소를 최적화할 수 있습니다. 마찬가지로 스택 가스 분석기는 스택 가스에서 질소 산화물 (NOx)과 황산화물 (SOx)의 농도를 측정하여 유해한 가스 배출을 줄이는 데 사용할 수 있습니다.

Enabling Technologies

Oxygen Analyzers

ZR Series Zirconia Oxygen Analyzers

Yokogawa 지르코니아 산소 분석기는 연소 모니터링 및 제어 애플리케이션에 사용되며 연소를 최적화하고 NOx 배출을 줄이기 위해 다양한 산업에 적용되고 있습니다.


Stack Gas Analyzer

SG750 Stack Gas Analyzer

SG750 스택 가스 분석기는 적외선 가스 분석기 유닛, 지르코니아 산소 분석기 유닛 및 샘플링 유닛으로 구성되며 최대 5개의 구성 요소 (NOx, SO2, CO2, CO 및 O2)를 동시에 측정할 수 있습니다.



Customer Challenge

혼합 연료 사용 시 일정한 증기 공급 유지

Solution

Yokogawa의 제어 시스템은 최적의 연료 혼합량을 계산하고 주 증기 압력을 안정화시키기 위해 연료 공급을 조정합니다.

Enabling Technologies

Transmitters

EJX/EJA Series Pressure Transmitters/Differential Pressure Transmitters

DPharp 디지털 압력 송신기 시리즈는 트랜스미터 기술에서 가장 혁신적인 기술 중 하나인 DPharp (Differential Pressure Precision Resonance Pressure) 센서를 사용합니다.


CENTUM VP

CENTUM VP Integrated Production Control System

CENTUM VP 통합 제어 시스템은 재생 가능 에너지 분야에서 최적의 생산성과 수익성을 위한 중단 없는 "Uptime 전용"시스템 성능을 보장합니다.

* Uptime : 가동시간


Exapilot

Exapilot Operation Efficiency Improvement Package

Exapilot은 운영자가 공장 운영 절차를 단계별로 안내하는 온라인 내비게이션 도구입니다. Exapilot은 표준 운전 절차 (SOP)를 자동화하고 프로세스 및 장치 이상을 조기에 감지합니다.



Customer Challenge

해수 누수 및 이온 교환 수지 손상을 탐를 위한 위한 장비 구매 및 유지 보수 비용

Solution

Yokogawa의 SC450G 전도도 분석기는 탈염수 관리 및 해수 누수 탐지를 위해 두 가지 분리된 범위에서 출력 신호를 생성하므로 두 가지 기능을 수행하기 위해 다른 장비를 구입할 필요가 없습니다.

Enabling Technologies

Conductivity Analyzers

Contacting Conductivity Analyzers

FLXA21은 차세대 모듈식 액체 분석기로 유연하게 pH/ORP를 측정하고 전도성, 유도 전도성 및 용존 산소량을 측정할 수 있습니다. FLXA21은 또한 동일한 유형의 센서를 최대 2개까지 설치할 수 있기 때문에 설치 비용을 줄이고 공간을 절약할 수 있습니다.



Details

Biomass Power Generation Process

바이오매스 발전소는 전형적으로 직접 연소, 혼합 연소 또는 가스화 형태입니다. 직접 연소 발전 방식의 경우 스팀은 목재 폐기물, 농업 폐기물 및 축산 폐기물과 같은 물질의 연소에 의해 발생된 열로부터 생성됩니다. 증기는 터빈을 회전시켜 전기를 생산하는 발전기를 구동합니다. 이 방법으로 바이오매스 물질의 안정적인 공급을 확보하고 이들 물질의 수분 함량을 균일하게 유지하는 것이 중요합니다. 혼합 연소 발전 방법은 안정적인 전기 흐름을 제공하기 위해 바이오매스와 석탄에 의존합니다. 바이오매스 연료가 부족하여 플랜트에 동력을 공급할 수 없으면 석탄이 추가됩니다. 가스화 발전 방법에서, 바이오매스를 가열하여 가연성 가스를 추출하고, 이를 정제하여 가스 엔진 또는 가스 터빈에 전력을 공급하여 발전합니다.

Control and Measurement Technologies

Biomass Power Generation Process

Plant-wide Systems and Instrumentation

Information

  • Operation support
  • Operation training
  • Plant asset management

Control

  • Integrated monitoring and control
  • Safety instrumentation

Measurement

  • Flow rate
  • Pressure
  • Liquid level
  • Temperature
  • pH
  • Conductivity
Processes
Fuel Unloading Boiler Turbine
  • Fuel unloading
  • Mixed combustion control
  • Ratio distribution control
  • Fuel charge quantity measurement
  • Steam pressure control
  • Combustion control
  • Combustion air control
  • Furnace draft control
  • Feed water control
  • Steam temperature control
  • Soot blower control
  • Flue gas O2 measurement
  • Main turbine control
  • Condenser level control
  • Deaerator level control
  • Cooling water control
  • Demineralizer control
Flue-Gas Treatment
  • Dust collector inlet temperature control
  • Flue-gas measurement (NOX, SO2, CO, CO2, O2, dust)
