벌크화학

석유 화학 제품, 무기물 또는 중간체를 생산하든 관계없이 화학 회사는 안전하고 호환되는 작업을 유지하면서 적시에 효율적인 방법으로 제품을 제공하는 비용과 마진 압박에 시달리고 있습니다. 또한 화학 회사들은 공급 원료 및 에너지 가격의 변동에 적응하고 가장 수익성 높은 제품 혼합을 시장에 제공해야 합니다.

Yokogawa는 벌크 화학 시장의 자동화 요구 사항을 세계적으로 지원해 왔으며 이 시장에서 인정받는 선두 주자입니다. Yokogawa는 제품, 솔루션 및 업계 전문 기술을 통해 시장 및 생산 요구 사항을 이해하고 플랜트의 수명주기를 통해 안정적이고 비용 효율적인 솔루션을 제공하기 위해 협력합니다.

Optimizing Production Planning

Yokogawa는 석유 화학 회사에 실질적인 혜택을 제공하는 제어 및 계측 솔루션을 구축할 수 있는 도구와 풍부한 경험을 보유하고 있습니다.

Challenges

원자재 가격과 제품 공급 및 수요의 변동은 생산 계획을 최적화하는 데 절대적으로 필요합니다.

Our Solutions

Yokogawa는 석유 화학 공정의 최적 스케줄링을 위해 기획과 제조 사이의 격차를 해소하는 생산 관리 시스템을 제공합니다.

Products & Solutions

Real-time Production Organizer™ : RPO

Real-time Production Organizer™ : RPO
RPO (Real-time Production Organizer™)는 생산 계획 및 프로세스 제어 사이의 격차를 해소하기 위해 특별히 개발된 플랫폼 응용 프로그램 모음으로 완전히 B2P (Business to Process) 생산 환경을 통합합니다.



Staying Globally Competitive

Yokogawa는 석유 화학 회사에 실질적인 혜택을 제공하는 제어 및 계측 솔루션을 구축할 수 있는 도구와 풍부한 경험을 보유하고 있습니다.

Challenges

글로벌 시장에서 경쟁력을 유지하려면 특정 사용자의 요구를 충족시키는 경쟁 제품을 개발하는 것보다 공장 전체의 프로세스 최적화가 중요함

Our Solutions

Yokogawa는 석유 화학 생산 워크 플로우를 민첩하고 유연하게 제어하고 안전 계장 시스템과 완벽하게 통합되는 공장 전체 자동화 솔루션을 제공합니다.

Product & Solutions

Production Control System: CENTUM VP

Production Control System: CENTUM VP
CENTUM VP 통합 제어 시스템은 최적의 생산성 및 수익성을 위한 중단없는 "Uptime 전용" 시스템 성능을 보장합니다.

* Uptime : 가동시간


Safety Instrumented System: Prosafe-RS
Safety Instrumented System: Prosafe-RS
ProSafe-RS 안전 계장 시스템은 진정한 통합 솔루션을 구현하는 동시에 안전 무결성 레벨 1-4 (SIL1-4) 애플리케이션에 필요한 고가용성을 제공합니다.
vigilantplant services.®
vigilantplant services.®
vigilantplant services.®는 Yokogawa의 VigilantPlant 개념을 실현하는 포괄적인 서비스 모음으로 제조업체가 안전하고 신뢰할 수 있으며 환경친화적이며 수익성 있는 공장 운영을 지원할 수 있도록 지원합니다.



Saving Energy and Reducing Greenhouse Gas Emissions

Yokogawa는 석유 화학 회사에 실질적인 혜택을 제공하는 제어 및 계측 솔루션을 구축할 수 있는 도구와 풍부한 경험을 보유하고 있습니다.

Challenges

석유 화학 플랜트는 엄청난 양의 에너지를 소비하므로 이러한 시설에서의 에너지 절약 의지는 지구 온난화에 기여하는 CO2 경쟁력을 높이고 비용 경쟁력을 확보하는 데 큰 도움이 됩니다. 이것이 달성될 수 있는 한 가지 핵심 수단은 생산 프로세스의 제어를 최적화하는 것입니다.

Our Solutions

Yokogawa의 첨단 공정 제어 시스템을 통해 발전소가 효율성 향상과 함께 작동하여 에너지 소비 및 CO2 배출량을 줄일 수 있습니다.

Products & Solutions

Solution-based Software
Solution-based Software
지속적인 개선 이니셔티브 및 생산 성능 최적화를 지원하는 통합 및 검증된 적시 운영 정보.
Contributing to a sustainable future
Contributing to a sustainable future
고객은 생산성 및 수익성 향상에 필수 요소인 품질, 비용, 납기 및 환경 (QCDE) 관리와 관련된 효율적인 플랜트 운영을 달성하는 데 있어 큰 어려움에 직면합니다. Yokogawa는 지속 가능한 미래를 위한 VigilantPlant 비전을 기반으로 이러한 과제에 대한 진정한 해결책을 제시합니다.

Reliability and Maintainability

수익 극대화를 위한 가장 근본적이고 종종 간과되는 요소 중 하나는 자동화 시스템의 안정성과 유지 보수성입니다. 최고의 시스템 가용성은 석유 화학 플랜트의 핵심 전제 조건입니다.

Reliability is in Our DNA

Reliability of The Production Control System

모든 자동화 공급 업체는 석유 화학 플랜트 가용성의 핵심 요소인 시스템 안정성을 심각하게 고려합니다. 그러나 Yokogawa의 과도한 공약에는 일치하지 않습니다. 회사의 모든 시스템의 중심에는 고유한 "Pair and Spare" 컨트롤러 아키텍처가 있으며 이 중에는 각각 2개의 마이크로프로세서가 포함된 중복 CPU 모듈 세트가 있습니다. 두 개의 마이크로프로세서는 서로의 출력을 지속적으로 비교하여 불일치가 발견되면 범프 없는 스위치 오버를 시작합니다.
Yokogawa CENTUM VP 분산 제어 시스템 (DCS)의 실제 가동률 기록은 99.99999% (Seven9s)에 도달합니다.



Production Control System : Pair and Spare  Architecture

CENTUM VP : "Pair and Spare" Architecture



Reliability of Safety Instrumented System (SIS)

Yokogawa의 안전계장 시스템인 ProSafe-RS는 세계 최초의 진정한 안전 계장 시스템입니다. 생산 제어 시스템과의 통합 아키텍처는 운영자에게 통합 모니터링 및 운영 환경을 제공합니다. 독일 인증 기관인 TUV Rheinland (TUV)는 ProSafe-RS가 IEC 61508 및 IEC 61511 국제 표준을 준수함을 인증했습니다. 또한 TUV는 긴급 차단 (ESD), 화재 및 가스 (F & G) 및 보일러 관리 (BMS) 와 같은 SIL3 (Safety Integrity Level 3) *1 애플리케이션에서의 사용을 승인했습니다. 이 최신 IEC 61508 및 IEC 61511 인증은 Yokogawa 기술의 높은 수준과 안전 계측 시스템의 품질을 입증합니다.

(*1)SIL3 인증을 받으려면 1/10,000 미만의 위험 요소에 대해 안전 시스템을 제3자가 테스트해야 합니다.



Safety Instrumented System : SIL3 TÜV Certificate

ProSafe-RS : SIL3 TÜV Certificate

Improving Maintainability by Diagnostic Technologies

Improved Plant Maintenance

Yokogawa의 자산 관리 시스템은 FOUNDATION fieldbus™ 또는 필드 장치와의 HART 연결을 활용하여 장비 유지 보수성을 크게 개선하여 유지 보수 비용을 절감합니다. 이제 유지 보수 직원은 언제 어디서나 필드 장치 정보에 액세스할 수 있습니다. 이 시스템을 통해 직원은 현장 장치 매개 변수를 설정 및 수정하고 자세한 장치 경보 정보를 확인할 수 있습니다. 표준 감사 추적 관리를 통해 장치 정보의 변경 내용을 추적할 수 있습니다.

Asset Management System : PRM System Configuration

PRM : PRM System Configuration

Device Diagnosis

FOUNDATION fieldbus™ 기술의 도입과 HART와의 호환성으로 필드 장치 자체 진단의 결과가 DCS 제어 작업에 정확하게 반영될 수 있습니다. 자가 진단의 예에는 다음이 포함됩니다.

Valve positioner

  • Signature diagnosis
  • Valve stick-slip diagnosis

Differential pressure / pressure transmitter

  • Clogging diagnosis
  • Orifice wearing diagnosis
  • Diaphragm corrosion diagnosis

Temperature transmitter

  •  Temperature element diagnosis

Vortex flowmeter

  • Clogging diagnosis
  • Vibration diagnosis

예측 유지 보수를 기반으로 하는 보다 높은 유지 보수 효율성을 위해 이 시스템은 고급 진단 기능도 제공합니다. 이러한 기능을 통해 스태프는 여러 장치 또는 상위 수준의 프로세스 종속 진단 정보를 사용하여 진단을 정의하고 수행할 수 있습니다. 고급 진단 예제는 다음과 같습니다.

Differential pressure / pressure transmitter

  • Impulse line blocking diagnosis
  • Steam tracing diagnosis

Valve positioner

  • Instrument air-line clogging diagnosis

Temperature transmitter

  • Environmental temperature monitoring
Automation Devices & Process Interface Diagnostics

Yokogawa의 혁신적인 자산 관리 시스템은 현장 장치의 효율적인 유지 관리에 필요한 모든 기능을 제공합니다.

Plant-wide Automation

Yokogawa는 복잡하고 다양한 석유 화학 제품 생산 프로세스에 대한 정보 사용에 대한 광범위한 실습을 제공하는 자동화 공급 업체입니다. Yokogawa는 석유 화학 생산 워크 플로우에 민첩성과 유연성을 제공하는 통합 공장 전체 자동화 솔루션의 최고 공급 업체입니다.


Petrochemical Complex

Products & Solutions

 Field Instruments

  • Differential Pressure/Pressure Transmitters
  • Multivariable Transmitter
  • Temperature Transmitters
  • Level Transmitters
  • Vortex Flowmeters
  • Coriolis Mass Flowmeter
  • Ultrasonic Flowmeters
  • Magnetic Flowmeters
  • Valve Positioners & Converters
  • Fieldbus Instruments


Field Instruments

 Environmental & Analytical Instruments

Gas Analyzers

  •  Process Gas Chromatographs
  • Gas Density Meters
  • Oxygen Analyzers
  • Infrared Gas Analyzers
  • Stack Gas Analyzers
  • Dust Monitors

Liquid Analyzers

  • Fourier Transform Near-Infrared Analyzers
  • Liquid Density Meters
  • pH/ORP Meters
  •  Conductivity Meters
  • Residual Chlorine Analyzers
  • Alkalinity Meters
  • Dissolved Oxygen Meters
  • MLSS Analyzers


Environmental & Analytical Instruments

 Harsh - Environment CCTV

  • Fieldeye CCTV



Harsh - environment CCTV

 Production Control System

  • CENTUM VP
  • System Migration



Production Control System

 Safety Instrumented System

  • ProSafe-RS


Safety Instrumented System

 Production Management Solutions

  • Plant Information Management System
  • Event Driven Integrated Reporting System
  • Operation Efficiency Improvement
  • Event Analysis
  • OPC Interface
  • Value-added Information Sourced Applications


Production Mnagement Solutions

 Advanced Process Control & Optimization Systems

  • Advanced Process Control Suite
  • Multi-Variable Model Predictive Controller
  • Robust Quality Estimator
  • Control Application Standards


Advanced Process Control & Optimization Systems

 Asset Management System

  • Plant Resource Manager


Asset Management System

 Alarm Management System

  • Advanced Alarm Administrator
  • Alarm Management Solutions
  • Consolidated Alarm Management System


Alarm Management System
