해상플랜트 (FPSO FLNG & FSRU)

해상 탐사 및 생산에는 열악한 조건 아래 최대의 가동 시간이 요구됩니다. 유인 및 무인 시설에서는 신뢰성이 확보된 원격 모니터링 기능을 갖춘 안정적인 통합제어 및 안전시스템 (ICSS)이 필요합니다. Yokogawa는 모든 규모 및 복잡한 자동화 단계의 해양프로젝트를 수행하는 데 있어 최첨단 기술과 광범위한 경험을 보유하고 있습니다.

Customer Challenge

시스템 통합

Our Solutions

FPSO용 통합 제어 및 안전 시스템 (ICSS) 공급 업체인 CENTUM VP 프로세스 제어 시스템 (PCS) 및 선체/윗면 제어를 위한 ProSafe-RS 안전 시스템, 해저 컨트롤 및 인터페이스 솔루션을 갖춘 터렛 계류 시스템 및 계측기 관리를 위한 PRM (Plant Resource Manager) 패키지 이들은 기계 모니터링 시스템, 프로세스 데이터 서버 및 운영자 교육 및 유지 보수 시스템과 같은 타사 시스템과 통합되어 있습니다.

ICSS는 관련 상부 시설, 규정 제어 및 켜기/끄기 제어를 비롯한 처리 시설의 모니터링 및 제어를 수행합니다. 또한 프로덕션 데이터 보고서, 다른 하위 시스템 및 휴먼 머신 인터페이스 (HMI) 콘솔, 아카이브, 기록과의 인터페이스를 생성하고 다른 인터페이스 시스템 및 관리 보고 시스템에 데이터를 전송합니다.
ICSS는 모든 제어 및 안전 기능의 중앙 집중식 공장 감독 및 관리를 가능하게 합니다.

Customer Benefits

안정적이고 효율적인 작동

Enabling Technology

CENTUM VP Integrated Production Control System

CENTUM VP는 Yokogawa의 최신 통합 생산 관리 시스템으로 분산 제어 시스템 (DCS)이라고도합니다. CENTUM VP는 보다 직관적인 HMI와 데이터를 빠르고 안정적으로 처리할 수 있는 보다 강력한 FCS를 갖추고 있습니다. 페어 및 스페어 CPU 구성과 같은 기능 덕분에 CENTUM VP는 99.99999% (Seven-9s) 가용성을 달성합니다.

ProSafe-RS Process Safety System

Yokogawa는 세계 최초로 프로세스 산업에 적합한 ProSafe-RS를 출시함으로써 기존에 DCS와의 비호환성의 시대를 끝내고 DCS와 완벽하게 통합할 수 있는 새로운 "안전 PLC"를 제시합니다.

Customer Challenge

유연하고 모듈 방식의 시스템 통합

Our Solutions

Yokogawa FLNG의 ICSS 아키텍처와 솔루션은 이 기술을 유연한 모듈 방식으로 활용합니다. Yokogawa는 "최초의 LNG"가 만들어지기까지 리스크를 최소화하기 위하여 설계, 설치 및 시운전 과정에서 전체 통합 모듈형 시스템을 설계할 때 분산형 ICSS 아키텍처를 최대한 활용합니다. 다른 프로세스 모듈의 자동 제어 및 안전/화재 및 가스 시스템이 전용 네트워크 세그먼트 및 컨트롤러는 물론 각 자치 시스템에 대한 분산 I/O 모듈을 활용합니다.

대규모 모듈의 경우 세그먼트를 지원하는 전용 운영 스테이션이 LER (Local Equipment Room)에 설치됩니다.

Floating Production Storage and Offloading (FPSO)




Photo courtesy of MODEC, Inc.



FPSO (Floating Production, Storage, and Offloading) 장치는 생산된 탄화수소에 대한 처리 장비와 저장 장치를 모두 저장하는 유동식 해양 생산 시설입니다. 탄화수소는 플랫폼 또는 해저 템플릿에 의해 생산된 다음 FPSO 시설로 전달됩니다. 그런 다음 FPSO 시설은 파이프라인이나 유조선을 통해 수송될 때까지 오일을 처리하고 저장합니다. FPSO (Floating Production Storage and Offloading) 장치는 석유 회사가 원거리 및 더 깊은 곳에서 석유를 경제적으로 생산할 수 있게 하는 데 사용됩니다.

Floating LNG (FLNG)

Yokogawa는 LNG 프로젝트를 수행하는 데 30년 이상의 경험을 갖고 있으며 중요한 엔지니어링 지식을 보유하고 있습니다. Yokogawa는 액화(Liquefaction), 재액화(Regasification) 및 LNG 운송에서 얻은 지식과 함께 해외 생산 시설에 대한 풍부한 경험을 결합하여 라이프타임 동안 FLNG 프로젝트를 수행하는 방법과 기능을 제공합니다.



FSRU (Floating Storage and Regasification Unit)

수년간의 연구 결과에 따르면 대규모의 부유식 생산, 저장 및 하역 (FPSO) 선박은 LNG 프로젝트를 위한 가능한 솔루션이 되고 있습니다. 역외 및 육상 천연가스 액화 및 재기화 공장은 서로 다른 요구 사항을 가지고 있지만, 검증된 액화 및 재기화 공정에 의존하고 있습니다. 밸러스트 및 화물 적재/하역 통제 또한 LNG선과 매우 유사합니다. Yokogawa는 풍부한 LNG 액화, 재기화 및 캐리어 경험과 다양한 종류의 부유식 생산 시스템에 대한 전문 지식을 바탕으로 LNG (FLNG) 및 플로팅 스토리지 및 재기화 장치 (FSRU) 프로젝트를 위한 다양한 생산 관리, 자산 관리, 안전 관리, 전원 관리 및 압축기 제어 솔루션을 제공할 수 있습니다.
