• DP Accuracy: ±0.055% of Span
• Stability: ±0.1% of URL per 10 years
• Static Pressure Accuracy: ±0.5% of Span
• MWP: 2,300 psi

• EJA115E Low Flow Transmitter
• DP Transmitter attached to IFO assembly based on EJA-E Series
• Measure accurately
• Transmit quickly
• Reliability over time

• DP Accuracy: ± 0.2% of Span
• Response Time: 200 msec
• Static Pressure Accuracy: ±0.5% of Span
• MWP: Up to flange rating

• Accuracy: ± 0.2% of Span
• Stability: ± 0.3% of URL per 1 year
• Draft Range

• DP Accuracy: ± 0.055% of Span
• Stability: ± 0.1% of URL per 10 years
• Static Pressure Accuracy: ±0.5% of Span
• MWP: 4,500 psi

Flanged-mounted Differential Pressure Transmitter designed for Liquid-level applications based on the EJA-A Series.

Flange-mounted Differential Pressure Transmitter designed for Liquid-level applications based on the EJA-E series.

Traditional-mount Gauge Pressure Transmitter

• Accuracy: ± 0.055% of Span
• Stability: ± 0.1% of URL per 10 years
• MWP: 2300 psi

Gauge Pressure Transmitter with Remote Diaphragm Seal

• Accuracy: ± 0.2% of Span
• Response Time: 200 msec
• MWP: Up to flange limit

Traditional-mount High Gauge Pressure Transmitter

• Accuracy: ± 0.055% of Span
• Stability: ± 0.1% of URL per 10 years
• MWP: 7,200 psi

In-Line Mount Absolute Pressure Transmitter based on the EJA-E Series.

In-Line Mount Gauge Pressure Transmitter

• Accuracy: ± 0.055% of Span
• Stability: ± 0.1% of URL per 10 years
• MWP: 7,200 psi

• EJA564E (Gauge Pressure)
• Hygienic & sanitary transmitter
• Pressure applications requiring compliance with Food & Beverage and Pharmaceutical industry regulations

High-performance hygienic & sanitary transmitter for pressure and level applications requiring compliance with Food & Beverage and Pharmaceutical industry regulations.


• DP Accuracy: ± 0.04% of Span
• Stability: ± 0.1% per 15 years
• Static Pressure Accuracy: ±0.2% of Span
• MWP: 3,600 psi

• EJX115A Low Flow Transmitter
• Differential Pressure (DP) Flow Transmitter
• Attached to IFO assembly based on EJX-A Series

• DP Accuracy: ± 0.15% of Span
• Response Time: 200 msec
• Static Pressure Accuracy: ±0.2% of Span
• MWP: Up to flange rating

• Accuracy: ± 0.09% of Span
• Stability: ± 0.15% of URL per 1 year
• Draft Range

• DP Accuracy: ± 0.04% of Span
• Stability: ± 0.1% of URL per 15 years
• Static Pressure Accuracy: ±0.2% of Span
• MWP: 4,500 psi

Flanged-mounted Differential Pressure Transmitter designed for Liquid-level applications based on the EJX-A Series.

• Absolute Pressure transmitters compare a pressure relative to absolute zero pressure
• Any critical storage and delivery application (i.e., toxic gases)
• Vital to use static reference for accuracy

• Differential pressure (DP) flow measurement
• Common technology for measuring flow in a closed pipe

• Yokogawa differential pressure transmitters for industrial applications
• Compare two pressures and transmit the difference to a control unit

• Yokogawa’s sanitary level transmitter line
• Hygienic pipeline solutions for growing industries i.e. life sciences, food/beverage

• New DPharp EJX transmitters
• Latest addition to DPharp family's EJA series
• Next-generation multi-sensing technology
• Highest level of performance and precision

• Yokogawa pressure transmitters, and sensors
• Improve industrial operations
• Withstand harsh installation environments

Yokogawa offers a complete line of ISA100 compliant differential pressure, absolute pressure, and gauge pressure transmitters
