XS530 Wireless Pressure Monitoring Module
Increase field productivity with the versatile and convenient XS530 wireless water pressure sensor.
Designed to withstand even the harshest of environments, this waterproof, dustproof, and explosion-proof WiFi pressure transmitter is ready to go where you need it most. It can quickly and reliably communicate across distances of up to 6 miles/10 km, conveniently connecting users via a simple and intuitive smartphone Near Field Communication (NFC) interface, and its streamlined design simplifies maintenance, allowing users to easily replace the long-lasting battery without removing the measurement module from the piping.
• Supports hazard location installation
• Gas and liquid pressure sensor WiFi capable of communicating up to 6 miles/10 km
• Battery life of up to 10 years
• Easily monitor sensor status from a smartphone.
Benefits of Wireless Pressure Sensors
Hazardous Location Installation
The XS530 in combination with the XS110A can be installed in Zone 1 areas, such as petrochemical plants, paint plants, steel plants, where flammable gas or vapor may exist.
Long-Distance Communication
LoRaWAN has excellent sensitivity reception, good radio interference resistance, and offers a communication distance of six miles (10 km) or more in ideal conditions. This sensor can be installed anywhere need - over a vast area.
Modular Design
The design simplifies maintenance. Easily replaces the battery without removing the XS530 Pressure Measurement Module from the piping.
Excellent Environmental Resistance and Battery Powered
The XS110A supplies power to the XS530 via a built-in replaceable battery that can last up to 10 years. This waterproof, dust-proof, and explosion-proof wireless pressure monitor can operate in harsh environments can be installed anywhere in a plant (no power cables required).
Configure and Monitoring Sensor Status from a Smartphone
Using an Android-based smartphone with a Near Field Communication (NFC) interface makes the Bluetooth transducer configuration and status monitoring of sensors simple and intuitive.
Details
XS110A Wireless Communication Module
WIRELESS SPECIFICATIONS | Communication Protocol | LoRaWAN Class A EU868, AS923, US915 |
---|---|---|
Data Rate | 250 to 11000 bps*1 | |
Frequency | Available frequency bands vary depending on the country. Please check General Specifications for details. |
|
Radio Security | AES 128-bit encryption | |
RF Transmitter Power | Max. 7 dBm | |
Antenna | Built-in Omni-directional antenna | |
POWER SUPPLY SPECIFICATIONS | Battery | Lithium thionyl chloride battery (size D): 1 unit Rated voltage: 3.6 V Rated capacity: 19 Ah |
PERFORMANCE SPECIFICATION | Update Time | 1 minute to 3 days |
FUNCTIONAL SPECIFICATION | Output Signal | LoRaWAN*2 |
NFC Interface | NFC Forum Type 2 Tag | |
INSTALLATION ENVIRONMENT | Ambient Temperature Limits | Operating: –40 to 85 °C (–40 to 185°F) Storage: –40 to 85 °C (–40 to 185°F) |
REGULATORY COMPLIANCE STATEMENTS | Degrees of Protection | IP66/IP67 and Type 4X Apply when connected to the Measurement Module. |
Explosionproof | ATEX, IECEx, FM | |
PHYSICAL SPECIFICATIONS | Housing Material | Plastic (PC) |
Weight | 300 g (0.66 lb)*3 |
*1: Available data rate vary depending on the country.
*2: For detail on channel plan, refer to General Specifications.
*3: Without battery
XS530 Pressure Measurement Module
MEASUREMENT RANGE | Gauge Pressure *1 | Range | Measurement Range | Maximum Pressure |
---|---|---|---|---|
-E | -0.1 to 5 MPa*2 (–14.5 to 720 psi) |
7.5 MPa(1080 psi) | ||
-H | -0.1 to 35 MPa*2 (–14.5 to 5070 psi) |
50 MPa(7250 psi) | ||
Temperature | –40 to 85°C (–40 to 185°F) | |||
PERFORMANCE SPECIFICATIONS | Measurement Accuracy | Pressure*3: ± 0.25% of Full scale Temperature: ± 5°C typ. |
||
Update Time | 1 minute to 3 days | |||
Battery Characteristics | Battery life is 10 years under the following conditions*4 • Ambient temperature: 23 ± 2°C • Update Time: 1 hour |
|||
FUNCTIONAL SPECIFICATION | Fluid to be Measured | Gas, Liquid | ||
INSTALLATION ENVIRONMENT | Ambient Temperature Limits | Operating: –40 to 85°C (–40 to 185°F) Storage: –40 to 85°C (–40 to 185°F) |
||
Process Temperature Limits | –40 to 120°C (–40 to 248°F) | |||
REGULATORY COMPLIANCE STATEMENTS | Degrees of Protection | IP66/IP67 and Type 4X Apply when connected to the XS110A. |
||
Explosionproof | ATEX, IECEx, FM | |||
PHYSICAL SPECIFICATIONS | Process connection | 1/2 NPT female, 1/2 NPT male | ||
Housing Material | Stainless Steel | |||
Material of Process Connection | Diaphragm: Hastelloy C-276*5 Process Connector: 316L SST*6 |
|||
Weight | 600 g |
*1: Pressure measurement span cannot be changed
*2: Refer to Fig.1 if the pressure is below atmospheric pressure.
*3: Measurement Accuracy will be changed when electromagnetic noise is applied.
*4: Environmental conditions such as vibration may affect the battery life.
*5: Hastelloy C-276 or ASTM N 10276(equivalent to Hastelloy C -276)
*6: 316L SST or ASTM grade 316L
Sushi Sensor App
This software is used to perform the setting and status check of this product via the NFC interface.

Operating Environment | Item | Recommended System Requirements |
---|---|---|
OS | Android 5.1.1 or higher | |
CPU | Snapdragon 800 or better | |
Resolution | 1280 x 720 dots or more | |
NFC | Readers, Writer | |
GPS | Optional |
Applications of Wireless Pressure Sensors
- Online pressure monitoring of gauges
- Leakage monitoring of valves
- Clogging monitoring of piping and filters
